HK Audio LUNAR 110 XA – High-performance 10" active speaker with FIR DSP, Bluetooth TWS and 1200 W power output
The HK Audio LUNAR 110 XA is the most compact model in the new LUNAR series, a range developed to deliver professional-grade sound quality with exceptionally intuitive operation. Designed for mobile DJs, live performers, rental companies and versatile installation applications, it provides optimized sound performance instantly thanks to its built-in presets, without requiring advanced technical expertise. Its rugged design and German manufacturing ensure long-term reliability and performance.
Despite its compact footprint, the LUNAR 110 XA impresses with its power and precision. Its 10-inch woofer combined with a 1-inch compression driver is powered by a bi-amplified Class-D amplifier delivering up to 1200 W peak power. Its high-resolution 32-bit DSP operating at 48 kHz utilizes 60 dB/octave FIR crossover filters along with advanced phase correction to ensure natural, detailed and perfectly controlled sound reproduction, even at high output levels reaching up to 128 dB SPL.
Thanks to its four integrated presets (Music, Ext. Sub, Monitor and Voice), the HK Audio LUNAR 110 XA instantly adapts to a wide range of applications. It can be used as a standalone full-range speaker, as a stage monitor thanks to its 33° monitoring angle, or as a satellite speaker paired with a HK Audio PORTABLE SUB series subwoofer. Its intentionally simplified user interface allows for fast and efficient setup, making it ideal for events where quick deployment is essential.
Connectivity on the LUNAR series has also been designed to meet the needs of modern users. The speaker features a XLR / Jack Mic-Line combo input, a XLR Thru output, a Mix Out output that carries both analog and Bluetooth signals, as well as a Bluetooth 5.4 module with True Wireless Stereo (TWS). This technology allows two LUNAR 110 XA speakers to be wirelessly paired for true stereo playback from a smartphone, tablet or laptop computer. The system is completed by the DuoTilt 3°/7° pole mount, M8 rigging points and a robust wooden enclosure designed for both mobile and fixed-installation applications.
Features & Specifications:
- Type: 2-way active bass-reflex loudspeaker
- Low / Mid Driver: 1 x 10" with 2" voice coil
- High-Frequency Driver: 1 x 1" compression driver with 1" voice coil
- Amplification: Bi-amplified Class-D
- RMS Power: 600 W
- Peak Power: 1200 W
- Maximum Sound Pressure Level: 128 dB SPL Peak
- Sensitivity: 110 dB (1 W / 1 m)
- Frequency Response (-6 dB): 66 Hz – 18 kHz
- Frequency Response (-10 dB): 61 Hz – 20 kHz
- Coverage Pattern: 90° x 55° (H x V)
- Crossover Frequency: 2.5 kHz FIR crossover, 60 dB/octave
- DSP: 32-bit / 48 kHz with FIR filters and phase correction
- Presets: Music, Ext. Sub, Monitor, Voice
- Protection Circuits: Subsonic filter, Peak, RMS and multiband limiters
- Analog Input: 1 x balanced XLR / Jack Mic/Line combo
- Thru Output: 1 x balanced XLR
- Mix Out Output: 1 x balanced XLR
- Bluetooth: Version 5.4 with True Wireless Stereo (TWS)
- Power Supply: IEC connector
- Mounting Options: DuoTilt 3°/7°, 4 x M8 rigging points, 33° monitor angle
- Handles: 2 x SingleGrip handles
- Construction: Rugged wooden enclosure
- Manufacturing: Made in Germany
- Warranty: 5 years after registration on the HK Audio website
- Dimensions: 324 x 524 x 334 mm
- Weight: 16 kg
Key Points:
- Professional 10" active speaker designed for DJs, live performance and sound reinforcement
- 1200 W peak Class-D amplification with silent fanless operation
- 32-bit / 48 kHz DSP with FIR filters and phase correction
- 4 integrated presets: Music, Ext. Sub, Monitor and Voice
- Bluetooth 5.4 with True Wireless Stereo
- XLR/Jack Mic-Line combo input with Thru and Mix Out outputs
- Versatile operation: FOH, stage monitor or satellite speaker with subwoofer
- 128 dB SPL maximum output for excellent dynamic headroom
- DuoTilt 3°/7° pole mount for optimized audience coverage
- 4 x M8 rigging points for suspended installations
- Rugged wooden enclosure suitable for mobile and fixed applications
- German engineering and manufacturing with a 5-year warranty after registration
