Chauvet DJ Shocker FX – Multifunction Blinder, Wash and Strobe Fixture with RGB and Cool White Zones
The Chauvet DJ Shocker FX is a versatile effect fixture designed to instantly create dynamic and impactful lighting atmospheres. Combining blinder, wash and strobe functions in a single compact unit, it enables DJs, event professionals, clubs and entertainment venues to produce professional visual effects with quick and intuitive operation. Thanks to its built-in presets, different lighting looks can be selected in seconds, even without complex programming.
The Chauvet DJ Shocker FX features 280 RGB LEDs distributed across 8 independent color zones, along with 56 cool white LEDs arranged in 4 separate sections. This architecture allows the creation of sophisticated lighting animations, dynamic chases, sweeping effects and powerful flashes. The control zones can be combined with the numerous built-in macros to achieve visually impressive results while reducing programming time.
With multiple DMX personalities offering up to 43 channels, the Chauvet DJ Shocker FX integrates easily into professional lighting systems. It can also operate in standalone mode, master/slave mode, or be controlled remotely using the optional IRC-6 remote control. This flexibility makes it an excellent choice for both mobile events and fixed installations requiring professional-quality strobe, wash or blinder effects.
Its low power consumption, lightweight 1 kg design and power-linking capability greatly simplify setup and installation. With a wide 97° beam angle and 139° field angle, the Chauvet DJ Shocker FX can efficiently illuminate large areas while producing spectacular lighting effects suitable for concerts, private events, DJ performances and stage productions.
Features & Specifications:
- Light source:
- 280 RGB LEDs
- Total RGB output: 50 W
- 56 cool white (CW) LEDs
- Total CW output: 11 W
- Estimated lifespan: 50,000 hours
- Control zones:
- 12 independent sections
- 8 RGB zones
- 4 cool white zones
- Built-in effect macros
- Lighting effects:
- Blinder, wash and strobe functions
- Programmable dynamic effects
- Strobe rate: 0 to 20 Hz
- Control:
- DMX: 8, 18, 30 or 43 channels
- Standalone mode
- Master/slave mode
- Optional IRC-6 remote control
- Connectivity:
- 3-pin XLR DMX input/output
- Power linking capability
- Optical performance:
- Beam angle: 97°
- Field angle: 139°
- Illuminance: 219 lux @ 2 m
- Power:
- 100 to 240 VAC, 50/60 Hz
- Power consumption: 45 W
- 0.6 A @ 120 V
- 0.4 A @ 230 V
- Up to 20 units power linked at 230 V
- Dimensions & weight:
- 260 x 70 x 160 mm
- Weight: 1 kg
- Certifications:
- Included:
- Shocker FX
- Power cord
- Quick Reference Guide
Key Points:
- 3-in-1 fixture combining blinder, wash and strobe functions.
- 12 independent control zones for advanced lighting animations.
- 280 RGB LEDs and 56 cool white LEDs for powerful and versatile output.
- Built-in effect macros for fast and easy setup.
- Up to 43 DMX channels for detailed programming possibilities.
- IRC-6 remote compatible for simplified control.
- Wide light coverage with a 97° beam angle and 139° field angle.
- Standalone and master/slave modes for maximum flexibility.
- Power linking capability to reduce stage cabling requirements.
- Compact and lightweight design ideal for mobile entertainment applications.
