Audiophony CARBON15A – 15″ 1500 W RMS active speaker with DSP, Bluetooth TWS and mobile app control
The Audiophony CARBON15A is a professional 15-inch active loudspeaker designed to deliver high sound power and great versatility of use. Delivering up to 1500 W RMS and a maximum sound pressure level of 131 dB SPL, it is suitable for mobile performances, DJ sets, live events, as well as fixed installations requiring a reliable and powerful system.
Thanks to its built-in DSP with 2.4-inch color display and control via the CARBONcontrol app (iOS/Android), the Audiophony CARBON15A allows advanced control of all audio parameters: parametric EQ, presets, modes, positioning, delay, scene management and much more. Its 4-way DSP architecture provides highly comprehensive configuration flexibility.
In terms of sound reproduction, the Audiophony CARBON15A features a high-efficiency 15″ woofer paired with a 1.35″ polymer compression driver, ensuring precise, clear and balanced audio reproduction. The 90° × 70° dispersion horn provides even coverage of the listening area.
Its robust design is based on a nitrogen-injected molded plastic enclosure, increasing rigidity by 20% while improving acoustic performance. The system is completed by a bi-amplified Class D amplifier (1000 W low frequencies + 500 W high frequencies) for high efficiency and reduced weight.
Connectivity includes 2 combo XLR/JACK MIC/LINE inputs with auto-detection, a Bluetooth input and a XLR LINK output with Bluetooth TWS compatibility for wireless stereo streaming. The Audiophony CARBON range is designed as a complete ecosystem, built to easily scale according to sound reinforcement needs.
Specifications:
- Speaker size: 15" woofer – 2.5" voice coil, 60.1 Oz magnet, 2 Ohms – 500 W AES / 1000 W Program
- HF driver: 1.35" polymer compression driver – 4 Ohms – 50 W AES
- Amplification: Class D 1000 W RMS (low) + 500 W RMS (high)
- Total power: 1500 W RMS / 3000 W max
- Frequency response: 45 Hz – 20 kHz
- Dispersion (H x V): 90° x 70° (at 10 kHz)
- Max SPL (@1m): 131 dB
- Built-in DSP: Normal / Live / Club / Speech modes, Position (Stand / Monitor / Pole), PEQ, Delay, Ducking, scenes, LED management, reset, system info
- Inputs: 2 x combo XLR/JACK MIC/LINE with auto-switch + Bluetooth
- Outputs: 1 x XLR LINK + Bluetooth TWS
- DSP input functions: EQ, Treble, Bass, presets (Live / Vocal / Custom)
- Main functions: Delay, HPF, full ducking (threshold, source, attenuation, release), modes and positioning
- Construction: Reinforced nitrogen-injected molded cabinet, full metal grille, Power/Clip LED, 3 handles, 3 x M10 mounting points
- Mounting: 36 mm pole socket, 6 rubber feet (4 bottom + 2 side)
- Weight: 22 kg – Dimensions: 430 × 403 × 713 mm
- Power supply: 220–240 V AC • 50 Hz (SMPS) – 1.80 m Seetronic power cable
- Protection: Thermal, short-circuit, limiter
Key Points:
- High power output of 1500 W RMS with bi-amplified Class D amplification
- 15″ high-efficiency woofer for enhanced low-frequency response
- Full DSP with 2.4″ display and advanced audio parameter control
- CARBONcontrol mobile app (iOS/Android) for remote adjustment
- Bluetooth TWS for quick and easy wireless stereo pairing
- 90° x 70° dispersion for even sound coverage
- Robust design with nitrogen-injected cabinet (+20% rigidity)
- Full connectivity with 2 combo inputs + XLR LINK output
