Chauvet DJ Sentinel Wash Q120 – 120 W RGBW Wash Moving Head with Fresnel Lens
The Sentinel Wash Q120 fits perfectly into the new generation of modern lighting fixtures alongside the Sentinel Spot Q60 ILS and the Sentinel Wash Q7Z ILS. With its high-power 120 W RGBW LED, it delivers a powerful, smooth, and perfectly balanced wash suitable for modern professional applications.
Thanks to its Fresnel lens, the Sentinel Wash Q120 produces an elegant, soft, and wide beam, ideal for stages, performers, dancefloors, or permanent installations requiring a refined and professional look. Its RGBW color mixing ensures rich, deep, and perfectly balanced colors.
Simplicity and efficiency are at the core of its design: the Q120 features synchronized automatic programs (Master/Slave), wide Pan/Tilt movements of 540°/260°, and a clear full-text LCD interface. It is also equipped with a USB-C port for firmware updates.
The Sentinel Wash Q120 can be operated without DMX thanks to the optional IRC-6 remote control, allowing quick and easy operation. Its power linking capability simplifies installation and significantly reduces cabling.
Compact, lightweight, and efficiency-oriented, the Sentinel Wash Q120 is the ideal solution for mobile DJs, rental companies, and professional installations looking for a powerful, elegant, and easy-to-use wash fixture.
Specifications :
- Type: RGBW wash moving head with Fresnel lens
- Light source: 120 W quad-color RGBW LED (≈ 50,000 h)
- Beam angle: 16°
- Pan/Tilt movement: 540° / 260°
- Pan/Tilt ranges: 180°, 360°, 540° pan / 90°, 180°, 260° tilt
- DMX: 10 or 14 channels
- DMX connectors: 3-pin XLR
- Strobe frequency: 0 to 20 Hz
- Illuminance: 8,710 lux @ 2 m
- Input voltage: 100–240 VAC, 50/60 Hz (auto-ranging)
- Power & current: 152 W, 2.2 A @ 120 V • 148 W, 1.4 A @ 230 V
- Power linking: 3 units @ 120 V; 5 units @ 230 V
- Wireless control: IRC-6 remote (optional)
- USB-C port: Yes (firmware updates)
- Dimensions: 163 × 143 × 255 mm
- Weight: 3.5 kg
- Certifications: CE, RoHS
- Cable length: 1.5 m
- Mounting: 13 mm mounting hole
- Included: power cable, mounting bracket, quick start guide
Key Points :
- Powerful 120 W RGBW LED for smooth, even output
- Fresnel lens for soft and aesthetic beam rendering
- Simple control via IRC-6 (no DMX required)
- Fast movements (540° Pan / 260° Tilt)
- Synchronized auto programs (Master/Slave)
- Full-text LCD display
- USB-C port for updates
- Power linking to reduce cabling
- Compact and lightweight, ideal for mobile setups
