CHAUVET DJ Freedom Par Q9 - 100% wireless RGBA LED projector on battery
The Freedom Par Q9 embodies the evolution of the Freedom series by combining light power, control versatility and total wireless freedom. This compact projector 9 RGBA LEDs of 6 W offers an impressive luminous rendering (up to 3580 lux @ 2 m) while remaining discreet and simple to install. Designed to work 100% on battery, it incorporates a d-Fi transmitter/receiver for wireless DMX control, as well as rF receiver allowing intuitive control via RFC or RFC-XL (optional), no sight line required.
Ergonomics is at the heart of the Q9 design: sound oLED full-text screen facilitates settings, while the adjustable range (from 3 to 12 hours) ensures performance adapted to all types of events, without compromise. The magnetic diffuser supplied allows to change the angle of the beam in one gesture, while its retractable spring foot allows a precise orientation of the beam. The mix of colours is optimized by new secondary optics, ensuring homogeneous projection without artifacts visuals.
Freedom Par Q9 is part of the Freedom range philosophy: versatility, reliability, mobility. With his robust chassis, its small dimensions, and sound light weight of 2.1 kg, it fits perfectly into structures or decorations, and is also suitable for applications indoors as temporary outdoors. He benefits from battery protection system for greater sustainability, and professional dimmer curves providing particularly fluid melts and light transitions.
Characteristics:
- RGBA LED projector wireless, on battery
- Light source : 9 x RGBA LEDs (6 W)
- Colour mix : Secondary optics for rendering without artifacts
- Beam angle : 12°
- Field angle : 35°
- Lighting : 3580 lux @ 2 m (without diffuser) - 529 lux @ 2 m (with diffuser)
- Luminous flux : 1161 lumens
- Monitoring : Integrated D-Fi transmitter/receiver, integrated RF receiver (RFC / RFC-XL), wireless DMX (4, 6 or 14 channels)
- View : OLED with full text
- Operating modes : DMX, Master/Slave, RF, Manual
- Adjustable autonomy 3, 5, 8 or 12 hours
- Charging time 3 hours
- Operating frequency : 2.412 to 2.484 GHz
- Strobe frequency 0 to 22 Hz
- Power source : Entry : 24 VDC, 1.5 A / external sector block : 100–230 V AC, 50/60 Hz
- Included : Magnetic diffuser, power source external, quick reference guide
- Compatible controllers : RFC, RFC-XL, FlareCON
- Fixing : M12 cutting
- Approvals : EC, UKCA, RoHS, FCC
- Dimensions (W x H x P) : 120 x 126 x 120 mm
- Weight (kg) : 2.1
Key Points:
- RGBA 9 LED projector (6 W) with secondary optics for a precise colour mix
- 100% wireless : integrated battery, DMX D-Fi + RF receiver for remote control
- Adjustable autonomy (3 to 12 hours) with quick charging (3h)
- Magnetic diffuser included to extend the cover angle
- Compact and light, ideal for square structures or discreet placements
