The NC3FD-V-B is a xLR base female 3 points designed for vertical mounting on printed circuit board (PCB). It is part of the universal series in D format of Neutrik, with a robust black metal housing and gold plated contacts ensuring optimal conductivity and wear resistance. The internal latch lock allows assembly and a map independent test before final fixation in the housing, a major asset for integrators and manufacturers of professional audio equipment.
This connector is ideal for equipment requiring excellent protection against RF interference, thanks to its three shielding contacts, while offering a great mechanical reliability (>1000 connection cycles). The modular construction with removable insert simplifies installation and maintenance. Compliant with standards IEC 61076-2-103 and UL94 V-0, this base is perfectly suited to demanding professional audio environments rear or front panel mounting.
Characteristics:
- Connector XLR 3 pin female
- Assembly : Vertical on PCB
- Frame format : D (metal, black)
- Contact resistance : < 3 m
- Mount orientation : front or rear
- Contacts : Bronze CuSn6 gold plated (0.2 μm Au over 2 μm Ni)
- Contact resistance Not less than 5 m
- Life > 1000 cycles
- Protection index : IP40
- Nominal current by contact : 6 A
- Operating temperature : -30 °C to +80 °C
- Flammability : UL 94 V-0
- Approvals : UL, IEC 61076-2-103 compliant
- Weldability : IEC 68-2-20 compliant
Key Points:
- Explosion XLR female 3 pins for vertical mounting on PCB
- Black metal case in D format, robust and shielded
- Gold plated contacts for maximum conductivity
- Dismountable insert for simplified assembly and testing
- Locking by lock and Advanced RF Protection
