COLORband Q4 IP

Chauvet DJ COLORband Q4 IP – IP65 Waterproof 4-in-1 RGBA LED Bar with Multi-Zone Control

The COLORband Q4 IP is a rugged LED bar designed to deliver powerful lighting effects indoors or outdoors. Equipped with 12 x 6 W RGBA LEDs split into 4 independently controllable zones, it can be used as a wall wash, blinder, or for dynamic lighting effects. Its IP65-rated design makes it fully resistant to water, snow, dust, and sand — perfect for outdoor events in any weather conditions.

This fixture features a password-protected digital touchscreen to secure your settings, and a powerCON® TRUE1 connection for safe power linking and fast setup. The built-in GORE® valve prevents internal moisture buildup by allowing air exchange, extending the fixture's lifespan. Thanks to its high-frequency dimming, it provides flicker-free operation for video or photographic use.

Durable, reliable, and versatile, the COLORband Q4 IP is ideal for DJs, production companies, festivals, outdoor stages, or any installation requiring high-performance, weather-resistant, and easy-to-install LED lighting.

Technical specifications:

• 4-in-1 RGBA LED bar with 4 independent control zones


• IP65-rated design fully resistant to water, snow, dust, and sand


• Password-protected digital touchscreen for secure settings


• 12 x 6 W RGBA LEDs – lifespan: approx. 50,000 hours


• Strobe rate: 0 to 20 Hz


• PWM frequency: 4 kHz (flicker-free on camera)


• Beam angle: 14° / Field angle: 27°


• Illuminance: 7074 lux @ 2 m / 1209 lux @ 5 m


• Lumens: 2923


• Power linking: 9 units @ 120 V / 16 units @ 230 V


• Input voltage: 100 to 240 V AC, 50/60 Hz (auto-ranging)


• Power consumption: 87 W, 1.18 A @ 120 V, 60 Hz / 86 W, 0.67 A @ 230 V, 50 Hz


• Dimensions: 998 x 81 x 104 mm


• Weight: 5.35 kg


• DMX connectors: 3-pin XLR


• IP rating: IP65


• Certifications: CE, MET


• Included accessories: power cable, quick reference guide, warranty card



Key features:

• Weather-resistant: IP65 protection against water, snow, dust, and sand


• Versatile use: 4 independent zones for wash, blinder, or decorative effects


• Secure and reliable thanks to the password-protected touchscreen


• Flicker-free thanks to high-frequency dimming (ideal for video)


• Quick setup with powerCON® TRUE1 connections and power linking
