Chauvet DJ Intimidator Trio XD – The 3-in-1 Beam, Wash and Effects LED Moving Head with Motorized Zoom and Wireless DMX Control
The Chauvet DJ Intimidator Trio XD is a professional multifunction LED moving head that combines Beam, Wash and dynamic effects in a single fixture. Designed to provide maximum versatility for event professionals, mobile DJs, function venues, clubs and permanent installations, it combines a powerful RGBW LED light source, a motorized zoom, innovative continuously rotating honeycomb optics, and advanced automated control to create spectacular lighting effects with ease. Thanks to its all-in-one design, the Intimidator Trio XD effectively replaces multiple types of fixtures within a single lighting setup.
At the heart of the fixture, six 45 W RGBW LEDs deliver impressive light output capable of producing both tight 3° beam effects and wide 22° wash coverage thanks to the integrated motorized zoom. This broad zoom range makes it easy to adapt the lighting output to any application, whether creating sharp aerial beams, illuminating a stage or filling a dance floor with vibrant, even color washes.
One of the Chauvet DJ Intimidator Trio XD's signature features is its rotating honeycomb lens system, capable of continuous rotation. This innovative optical design generates eye-catching visual effects by constantly transforming the shape and movement of the light beams. Combined with RGBW color mixing, motorized zoom and fast pan/tilt movements, it creates complex lighting effects without requiring advanced programming.
The fixture also incorporates numerous features designed to simplify mobile productions. Its built-in automatic programs with zone control make it easy to generate dynamic lighting looks for parties, concerts, private events and permanent installations. The integrated Totem Mode automatically keeps the beams focused on the dance floor even when the fixture is mounted on truss towers or totems, ensuring professional-looking results with minimal setup.
Designed for modern lighting systems, the Chauvet DJ Intimidator Trio XD features an integrated D-Fi transceiver for wireless DMX control and Master/Slave synchronization, eliminating the need for additional DMX cabling. It also includes a built-in RF receiver compatible with the optional RFC and RFC-XL remote controls, providing convenient wireless operation during mobile events.
Its carbon fiber composite housing is another major advantage. Lighter than traditional metal construction while remaining exceptionally durable, it offers excellent corrosion resistance and makes transport and repeated setup much easier. Weighing only 9.3 kg (20.4 lb), the Intimidator Trio XD is ideally suited to touring and mobile productions without compromising reliability.
Operation is managed through a bright color LCD display that provides quick access to all fixture settings. Users can easily create, store and recall custom scenes directly from the fixture without requiring a DMX controller. An integrated USB-C port also allows convenient firmware updates to keep the fixture up to date with future Chauvet DJ enhancements.
Combining Beam, Wash and dynamic effects, wired or wireless DMX control, motorized zoom, innovative rotating optics and lightweight construction, the Chauvet DJ Intimidator Trio XD is a complete lighting solution for mobile DJs, event production companies, theaters, clubs, bars, permanent installations and live productions looking for a versatile professional LED moving head capable of delivering spectacular visual effects in a compact format.
Features & Specifications:
- Light Source & Optics:
- Professional Beam, Wash & Effects LED moving head
- 6 x 45 W RGBW LEDs (270 W total)
- Estimated LED lifespan: 50,000 hours
- Motorized zoom from 3° to 22°
- Continuous rotating honeycomb multi-lens optical system
- Dynamic visual effects with continuously evolving beam patterns
- Adjustable strobe from 0 to 20 Hz
- Movement:
- Pan: 540°
- Tilt: 270°
- Selectable pan ranges: 180°, 360° or 540°
- Selectable tilt ranges: 90°, 180° or 270°
- Fast and precise movements designed for professional productions
- Effects & Programs:
- Beam, Wash and Effects functions combined in a single fixture
- Built-in automatic programs with zone control
- Totem Mode keeps the beams automatically focused on the dance floor
- Create, save and recall custom scenes directly from the display
- Smooth and homogeneous RGBW color mixing
- Dynamic visual animations thanks to the continuously rotating lens system
- Control & Connectivity:
- DMX modes: 16, 23 or 52 channels
- 3-pin and 5-pin XLR DMX connectors
- Built-in D-Fi transceiver for wireless DMX operation
- Wireless Master/Slave capability
- Integrated RF receiver
- Compatible with optional RFC and RFC-XL remote controls
- USB-C port for firmware updates
- Color LCD display for local configuration
- Construction:
- Carbon fiber composite housing
- Lightweight, rugged and corrosion-resistant construction
- Designed for both mobile productions and permanent installations
- Weight: 9.3 kg (20.4 lb)
- Performance:
- Beam illuminance (3°): 124,299 lux at 2 m
- Wash illuminance (22°): 7,505 lux at 2 m
- Power consumption: 343 W (230 V)
- Universal power supply: 100 to 240 V AC – 50/60 Hz
- Power linking: up to 8 fixtures at 230 V
- Dimensions & Package Contents:
- Dimensions: 320 × 220 × 431 mm
- Weight: 9.3 kg (20.4 lb)
- Mounting bracket included
- Power cable included
- Quick Reference Guide included
- Certifications: CE, FCC, MET
Key Features:
- Professional 3-in-1 LED moving head combining Beam, Wash and dynamic Effects in one compact fixture.
- Motorized zoom from 3° to 22° for seamless transitions from tight beams to wide washes.
- Rotating honeycomb optics create unique visual animations and spectacular dynamic effects.
- Built-in wireless DMX via the integrated D-Fi transceiver with cable-free Master/Slave operation.
- Automatic programs, zone control and Totem Mode make it easy to create professional light shows without complex programming.
- Carbon fiber composite housing provides outstanding strength, lightweight portability and excellent corrosion resistance.
- Comprehensive control options via DMX, color LCD display, RFC/RFC-XL remote controls and convenient USB-C firmware updates.
- Powerful RGBW LED engine delivering up to 124,299 lux at 2 meters in Beam mode.
- Fast installation with universal power supply, power linking capability and multiple control options.
- The ideal solution for mobile DJs, event production companies, clubs, banquet halls, stages, bars, fixed installations and rental companies looking for a versatile, high-performance and easy-to-operate professional LED moving head.
