ANTELOPE AUDIO ATLAS I8

Dive into an incomparable sound experience with the Atlas i8, the high-end studio monitor designed for the most demanding professionals. With an innovative isobare design with two 8-inch serious speakers, this equipment offers powerful and precise bass, supported by a tailor-made Class D amplifier. Digital calibration with FIR and IIR filters ensures a neutral frequency response and a linear phase, while the 64-bit acoustic synchronization technology ensures an exceptional quality audio conversion.

With its coaxial driver for medium and acute frequencies, the Atlas i8 ensures optimal phase coherence, regardless of its orientation in your studio. Its careful design includes a colour display that provides easy access to advanced settings, including parametric equalization, delay lag and preset management. The 18 mm cabinet, reinforced to reduce resonance, offers a solid construction, while the optional mounting plate allows a flexible installation to the wall or ceiling.

Made by hand in Europe, the Atlas i8 is the ultimate tool for sound engineers, music producers and audio enthusiasts, offering unmatched clarity and precision on a wide range of frequencies ranging from 35 to 20,000 Hz, with a maximum SPL of 117 dB to 1 meter. Whether you were working in close-to-average monitoring, the Atlas i8 redefines the standards of audio studio, pushing the limits of sound perfection to allow you to create and produce with confidence.

Characteristics :

• Near studio monitor and active average distance


• Number of tracks : 3


• Isobaric design: 2 x 8'' speakers'


• Speaker medium/coaxial aigu


• Power 200 W + 200 W


• Double Class D amplification, total power 400 W


• Frequency response: 35 - 20000 Hz


• Output level max. : 117 DB SPL at 1 m


• Digital connectivity AES / EBU


• Digital calibration using FIR & IIR filters


• Linear phase frequency response


• Conversion technology AFC 64-bit


• Color setting screen


• Parametric equalizer


• Time management


• Horizontal or vertical positioning


• Analogue input on combo XLR/TRS


• Conversion AN/NA 24-bit 192 kHz


• Dimensions (W x H x P): 290 X 500 x 387 mm


• Weight (kg): 24
