ROTOGOBO ZOOM

JB Systems Rotogobo Zoom – LED Logo Projector with 20–34° Manual Zoom

The Rotogobo Zoom from JB Systems is a high-performance logo projector equipped with a 50 W cool white LED, making it ideal for shops, storefronts, events, galleries, and exhibitions. Its optimized design ensures very low gobo heating, allowing the use of standard metal or glass gobos, as well as plastic film gobos printed with a simple laser printer. A professional, cost-effective, and highly versatile solution.

This projector features a manual zoom ranging from 20° to 34°, combined with an adjustable focus to deliver sharp projection at any working distance. It comes with four free metal gobos: “Sale”, “Happy New Year”, “Gifts”, and “Hearts”.

The Rotogobo Zoom offers several operating modes: manual mode (dimmer, strobe, rotation) via IR remote control, master/slave mode for synchronized multi-unit setups, and DMX control (1, 2, 3 or 4 channels). It is also ready for use with the WTR-DMX wireless DMX dongle. Its 2×8 alphanumeric LED display provides fast and intuitive menu navigation.

With its extremely silent operation, it is perfectly suited to noise-sensitive environments such as shops, showrooms, and exhibition spaces.

Features and Specifications:

• Type: LED logo projector with manual zoom


• Light Source:
  • 50 W cool white LED
  • Very low gobo heating
  • Compatible with metal, glass, and printable plastic film gobos


• Optics:
  • Manual zoom: 20° to 34°
  • Adjustable focus
  • Sharp, precise projection


• Gobos:
  • 4 included metal gobos (Sale, Happy New Year, Gifts, Hearts)
  • Supports metal, glass and printable plastic gobos
  • Templates available online


• Operating Modes:
  • Standalone fixed
  • Standalone automatic
  • Manual mode (dimmer, strobe, rotation)
  • DMX control: 1/2/3/4 channels
  • Master/slave mode
  • IR remote control included


• DMX Connectivity:
  • 3-pin XLR input/output
  • Wireless DMX via optional WTR-DMX dongle


• Interface:
  • 2×8 alphanumeric LED display
  • Easy menu navigation


• Power:
  • Power consumption: 56 W
  • AC 100–240 V, 50/60 Hz


• Construction:
  • Indoor use (IP20)
  • Robust black housing
  • Very silent operation


• Dimensions: 50 × 15 × 10 cm


• Weight: 2.77 kg


• Connectivity:
  • Input: 3-pin XLR, PowerCON or compatible
  • Output: 3-pin XLR, PowerCON or compatible



Key Points:

• Powerful 50 W cool white LED ideal for logos and promotional projections


• 20–34° manual zoom with adjustable focus


• Low gobo heating: supports metal, glass and laser-printed plastic gobos


• 4 free metal gobos included


• 1 to 4 DMX channels + master/slave mode


• IR remote control included


• Wireless DMX-ready with optional WTR-DMX dongle


• Ultra-silent operation for shops and showrooms
